鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径

詳細情報
モデルNO: ZD-GALWIRE 適用する: ロープ、包み、構造囲う製造得る
合金でもなくとも: オーダーメイド スタンダード: BS、JIS、GB、ASTM、DIN、AISI
材料: ASTM A36 A572 A992 S235jr/J0/J2 S355jr/J0/J2 オーダーメイド: はい
カスタムサイクル: 7~15 日 製品名: 鋼鉄の電圧線
支払期間: 30%T/T 先払い + 70%残金 MOQ: 3トン
長さ: オーダーメイド 利点: 耐磨性,加工性,簡単に溶接可能
仕様2: Zd-Galwire5 6 7 8 9 10 仕様3: Zd-Galwire12 14 15 16 18
標準1: ASTM a 6/a 6m-07 BS 4-1:1993 EN 10024 JIS G 3192 輸送パッケージ: 輸出標準パッケージ/要求に応じて
仕様: 顧客の要求に応じて 商標: シェンゲ
原産地: 中国 HSコード: 7217200000
供給の能力: 50000トン/月
ハイライト:

鋼鉄線 0.7mm

,

鋼鉄線 0.8mm

,

鋼鉄線 1.2mm


製品の説明

Product Description

鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 0ZHENGDE Galvanized wire production process: It is processed by high-quality low-carbon steel wire rod, and the high-quality low-carbon steel is processed by drawing forming, pickling and derusting, high-temperature annealing, hot-dip galvanizing and cooling.
Galvanized wire characteristics: Galvanized iron wire has good toughness and elasticity, and the highest amount of zinc can reach 300 grams per square meter. It has the characteristics of thick galvanized layer and strong corrosion resistance.
Galvanized wire application: The products are widely used in various fields such as construction, handicrafts, weaving wire mesh, highway guardrails, product packaging and daily civilian use.
Galvanized wire is further divided into hot-dip galvanized wire and cold-dip galvanized wire (electro-galvanized wire), which are distinguished as follows:
Hot-dip galvanizing is dip-plating in a heated and melted zinc solution. The production speed is fast, and the coating is thick but uneven. The minimum thickness allowed by the market is 45 microns, and the maximum thickness can reach more than 300 microns. The color is darker, consumes more zinc metal, forms an infiltration layer with the base metal, and has good corrosion resistance. Hot-dip galvanizing can last for decades in outdoor environments.
Cold galvanizing (electrogalvanizing) is to gradually coat the metal surface with zinc through the unidirectional current in the electroplating tank. The production speed is slow, the coating is uniform, and the thickness is thin, usually only 3-15 microns. The appearance is bright and the corrosion resistance is poor. It usually rusts in a few months.
Compared with hot-dip galvanizing, the production cost of electro-galvanizing is lower.

Gauge SWG BWG AWG Metric system
in mm in mm in mm mm kg/km
0 0.324 8.23
1 0.3 7.02
2 0.276 7.01
3 0.252 6.401 0.259 6.58 0.2294 5.83
4 0.232 5.893 0.238 6.05 0.2043 5.19 6 220
5 0.212 5.385 0.22 5.59 0.1819 4.62 5.5 185
6 0.192 4.811 0.203 5.16 0.162 4.11 5 153
7 0.176 4.47 0.18 4.57 0.1443 3.67 4.5 124
8 0.16 4.064 0.165 4.19 0.1285 3.26 4 98
9 0.144 3.658 0.148 3.76 0.1144 2.91 3.5 95
10 0.128 3.251 0.134 3.4 0.1019 2.59 3.2 62
11 0.116 2.946 0.12 3.05 0.09074 2.3 2.9 51
12 0.104 2.642 0.109 2.77 0.08081 2.05 2.6 41
13 0.092 2.337 0.095 2.41 0.07196 1.83 2.3 32
14 0.08 2.032 0.083 2.11 0.06408 1.63 2 24
15 0.072 1.829 0.072 1.83 0.05707 1.45 1.8 20
16 0.064 1.626 0.065 1.65 0.05082 1.29 1.6 16
17 0.056 1.422 0.058 1.47 0.04526 1.15 1.4 12
18 0.048 1.219 0.049 1.24 0.0403 1.02 1.2 8
19 0.04 1.016 0.042 1.07 0.03589 0.91 1 6
20 0.036 0.914 0.035 0.89 0.03196 0.812 0.9 5
21 0.032 0.873 0.032 0.81 0.02846 0.723 0.711 3.2
22 0.028 0.711 0.028 0.71 0.02535 0.644 0.558 3.1
Our Advantages
鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 1
鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 2
鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 3

鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 4
鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 5

鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 6
鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 7
鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 8
鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 9



鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 10
Quality first: production and inspection in strict accordance with production standards;
Price advantage: discounts based on real market prices;
Transaction security: There will be no loss of customer funds;
After-sales guarantee: the customer's problem is our problem;
Long-term cooperation: quality assurance, price advantage, sincere service can last for a long time.
Detailed Photos

鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 11鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 12
鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 13

Packaging & Shipping

鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 14

Company Profile

鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 15Shandong Zhengde Metal Manufacturing Co., Ltd.  is a production and sales company integrating hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, section steel, steel pipes, steel wires, metal mesh, stainless steel, aluminum, copper and other metal products integrated large enterprises. Five production and sales bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan and Tai'an, with more than 100 production lines, 4 nationally recognized laboratories, 2 technical engineering centers, and 5 enterprise technology centers. Products are exported to more than 50 countries and regions such as North America, South America, Europe, Middle East region, Russia, Africa, North America, and other parts of the world.
Company Philosophy:
Quality first: production and inspection in strict accordance with production standards;
Price advantage: discounts based on real market prices;
Transaction security: There will be no loss of customer funds;
After-sales guarantee: the customer's problem is our problem;
Long-term cooperation: quality assurance, price advantage, sincere service can last for a long time.
If you encounter dishonest manufacturers during the procurement process, we can provide you with a professional legal team. We hope our cooperation is full of sunshine!
Welcome to the company for investigation and cooperation, and look forward to friendly cooperation with you!
Thank you for your support to our company. We are pleased to receive your inquiry and will reply to you as soon as possible.



鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 16

Certifications

鋼鉄線 0.7mm 0.8mm 1.2mm 1.6mm 1.8mm 2mm 直径 17


FAQ:

1. Are you a trading company or a factory?
A: We are a direct factory with more than 30 years of production experience, a professional technical team, production team, overseas sales team, can solve various problems for you

2 .What's your advantage?
A: Great products with competitive price and professional service on export business.

3. How I believe you?
A : We consider honesty as the core of our company, we can tell you the contact information of our some other clients for you to check our credit. Besides, there is trade assurance from , your order and money will be well guaranteed.

4.Can you give warranty of your products?
A: Yes, we extend a 100% satisfaction guarantee on all items. Please feel free to feedback immediately if you are not pleased with our quality or service.

5.Where are you? Can I visit you?
A: Sure,welcome to you visit our factory at any time.

6.How about the delivery time?
A: We have multiple warehouses, some products are in stock, and we can ship them to you immediately!
Other products that need to be produced will be produced within 10-15 days at the earliest according to your requirements; large orders will be produced according to the specific situation.

7.what kind of payment does your company support?
A: T/T, 100% L/C at sight, Cash, Western Union are all accepted if you have other payment,please contact me.
